Forte.js

Total compliance. Total control.


Securely capture payment information while maintaining complete control of your payment form and UX with Forte.js. Adding Forte.js to your HTTPS-hosted site reduces your PCI exposure by posting sensitive customer information directly to Forte's servers instead of your own. Forte.js also simplifies your payment processing by ensuring you don't have to worry about the complex security implications that arise when credit card or echeck data hits your server. Instead, after receiving a customer POST, Forte returns a single-use token to you, which you can use to create a transaction.



You can use Forte.js with your own payment form by declaring Forte attributes or by writing your own client-side script. Either integration option requires only a few lines of code.

Additionally, you can use the Forte.js one-time token with Forte's Advanced Gateway Interface or Forte's REST web services (e.g., one_time_token=ott_g7vnjqikszabzynu6eowbq), where you can create a permanent paymethod token from a one-time token.

The following steps detail how to integrate Forte.js into a payment form you create.

Step 1: Generate an API Login ID

Forte.js requires a merchant-specific API Login ID to accompany the POST call to the Forte servers. To generate this ID, complete the following steps:

  1. Log into your Virtual Terminal Account.
    NOTE: Contact your Forte account representative for a Virtual Terminal Merchant ID, User Name, and Password.
  2. Navigate to the Gateway Settings tab and click the Gateway Key icon (). The following screen displays:


  3. Click next to the API Login ID field. The application generates a new value.
  4. Record this newly generated value in a secure location.

  5. Click to save this value to your merchant account.



Step 2: Include Forte.js in the Payment Form

Add the following Forte.js references to the <head> tag of your payment form.

For the test environment:

<script type="text/javascript" src="https://sandbox.forte.net/api/js/v1"></script>



For the production environment:

<script type="text/javascript" src="https://api.forte.net/js/v1"></script>



Step 3: Create the Payment Form

Use one of the following two methods to create your one-time token.

Method 1: Declare Forte Attributes

The sample code below displays a simple payment form that you can use with the Forte.js script. The form declares forte-data attributes on the HTML elements according to the Forte.js API. For this option, include the API Login ID in the Submit button to automatically send the data to Forte's Transaction Processor. Note that the data input fields do not have "name" attributes. This ensures that customer data does not hit your server when the customer submits the form. Rather, the Forte.js script sends the sensitive data to the Forte Transaction Processor, which converts it into a one-time token that is returned to you.

For credit card payments, use the following form:

Credit Card Number:<input type="text" forte-data="card_number" />
Exp month:<select forte-data="expire_month">
      <option value="1">Jan - 1</option>
      <option value="2">Feb - 2</option>
      <option value="3">Mar - 3</option>
      <option value="4">Apr - 4</option>
      <option value="5">May - 5</option>
      <option value="6">Jun - 6</option>
      <option value="7">Jul - 7</option>
      <option value="8">Aug - 8</option>
      <option value="9">Sep - 9</option>
      <option value="10">Oct - 10</option>
      <option value="11">Nov - 11</option>
      <option value="12">Dec - 12</option>
   </select>
Exp Year:<select forte-data="expire_year">
      <option value="2014">2014</option>
      <option value="2015">2015</option>
   </select>
CVV:
   <input type="text" forte-data="cvv" />
<button type="submit" forte-api-login-id="API_LOGIN_ID" forte-callback-success="onTokenCreated" forte-callback-error="onTokenFailed">Submit</button>



For echeck payments, use the following form:

Account Number:<input type="text" forte-data="account_number" />
Routing Number:<input type="text" forte-data="routing_number" />
Account Type:<input type="text" forte-data="account_type" />


<button type="submit" forte-api-login-id="API_LOGIN_ID" forte-callback-success="onTokenCreated" forte-callback-error="onTokenFailed">Submit</button>



Method 2: Use a Client-Side Script

To integrate Forte.js into a more advanced, dynamic payment form, use your own JavaScript to submit payment information. To do this, add a handler like the one displayed below to your payment form. This handler captures the submit event and sends it to the Forte Transaction Processor. This integration option provides you with more flexibility because it does not require you to add Forte.js to a defined HTML form.

<script type="text/javascript">
      $(document).ready(function () {
         $('button[type=submit]').on('click', function () {
            var data = {
               api_login_id: 'API_LOGIN_ID',
               card_number: $('#cc').val(),
               expire_year: $('#year').val(),
               expire_month: $('#month').val(),
               cvv: $('#cvv').val(),
               account_number: $('#dda').val(),
               routing_number: $('#route').val()
               account_type: $('#type').val()
            }
forte.createToken(data) .success(onTokenCreated) .error(onTokenFailed);
return false; }); }); </script>



Declare the API Login ID and the following required input fields in the data object according to the Forte.js API.

Field Description Type
card_number The customer's credit card number string
expire_year The expiration year of the customer's credit card [max length = 4] string
expire_month The expiration month of the customer's credit card [max length = 2] string
cvv The card verification value of the customer's credit card [max length = 4] string
account_number The DDA account number associated with the customer's checking account. string
routing_number The transit routing number associated with the customer's bank. This field supports both US and Canadian routing numbers. For more information on formatting Canadian routing numbers, see the "General" section on the FAQ page. string
account_type

The customer's bank account type. Supported values for this parameter include the following:

  • c = Checking
  • s = Savings
string



Note that the sample code displayed above requires you to include your own jquery library.



Step 4: Capture the One-Time Token Response

After sending your payment form to the Transaction Processor, you must add a script that captures the event response to either continue the transaction process (for success events) or handle the error (for error events).

<script type="text/javascript">
      function onTokenCreated(response) {
         //do real transaction here by using the onetime_token
         alert("The onetime_token created: " + response.onetime_token);
      }
      function onTokenFailed(response) {
         //handle error here
         alert("Getting onetime_token failed: " + response.response_description);
      }
   </script>



The Forte Transaction Processor sends the one-time token in the response object along with the following parameters:

Parameter Description Type
event Indicates whether or not Forte successfully created the one-time use token. Use one of the following values for this parameter:
  1. success
  2. failure
string
request_id The request ID number the Forte Transaction Processor generated for this transaction. string
card_type Supported types include the following:
  • visa
  • mast
  • amex
  • dine
  • jcb
  • disc
string
expire_year The expiration year of the customer's credit card [max length = 4] string
expire_month The expiration month of the customer's credit card [max length = 2] string
one_time_token The one-time use token that Forte returns (e.g., ott_ki99oclmr8c0gduavrcjww)

NOTE: One-time tokens expire after 60 minutes.

string
last_4 The last four digits of the customer's credit card number or echeck account number string
account_type

The customer's bank account type. Supported values for this parameter include the following:

  • c = Checking
  • s = Savings
string
response_code A code that represents the transaction result. For more information on these
responses, see Response Codes.
string
response_description A text description of the transaction result string



The code sample below displays the response object of a successful event:

{
  "event":"success",
  "request_id":"e0068a76-d41a-44af-e80a-e92d94e5d397",
  "card_type":"mast",
  "cvv":"123",
  "expire_year":"2015",
  "expire_month":"01",
  "one_time_token":"ott_ki99oclmr8c0gduavrcjww",
  "last_4":"4444",
  "response_code":"A01",
  "response_description":"APPROVED"
}


The following code sample displays the response object of an error event. Note that the Forte Transaction Processor only sends the response_description parameter for failure events.

{
  "event":"failure",
  "response_description":"The card_number is invalid."
}

The following table details potential errors you could encounter when using Forte.js.

The browser you are using is not supported. Fortejs supports the latest versions of the following browsers: Internet Explorer, Firefox, Chrome, and Safari.
The browser you are using is not supported. Please download the latest version of your browser to use Fortejs.
The api_login_id is required.
The expire_month is required.
The account_number is required.
The routing_number is required.
The routing_number is invalid.
The account_type is required.
The account_type is invalid.
The expire_year is required.
The cvv is required.
The card_number is invalid.
The cvv is invalid.
The expire_month and expire_year are invalid.
Invalid authentication.
